Internal Halyard Flagpole with Winch

Product Description

Internal Halyard Flagpole with Winch

(PLEASE CALL SANDRA FOR FREIGHT QUOTE OR FOR INSTALLATION QUOTE) 877-352-4755

Internal Halyard – Revolving
Wire Cable Halyard With Winch

The Titan Series from American Flagpole is the perfect choice when your project calls for commercial-grade flagpoles with the extreme security of a heavy-duty cable and winch system. The concealed internal halyard allows the graceful taper of the flagpole to be unobstructed, while the stainless steel wire cable and lockable door provides owners the peace of mind obtained with 24-7 security.



Cable flagpole

Internal halyard flagpole

Items highlighted in green are usually stocked in the satin finish & deliver within 1 to 2 weeks. Others may take 3-6 weeks.

Internal Halyard Flagpole with Winch

Click below for shop drawings

IWW20C61-02, 20′, Butt Dia. 6″, Wall Thickness .156″
IWW20D61-02, 20′, Butt Dia. 6″, Wall Thickness .188″
IWW25C61-02, 25′, Butt Dia. 6″, Wall Thickness .156″
IWW25D61-02, 25′, Butt Dia. 6″, Wall Thickness .188″
IWW30C61-02, 30′, Butt Dia. 6″, Wall Thickness .156″
IWW30C71-02, 30′, Butt Dia. 7″, Wall Thickness .156″
IWW30D61-02, 30′, Butt Dia. 6″, Wall Thickness .188″
IWW30D71-02, 30′, Butt Dia. 7″, Wall Thickness .188″
IWW35C71-02, 35′, Butt Dia. 7″, Wall Thickness .156″
IWW35D71-02, 35′, Butt Dia. 7″, Wall Thickness .188″
IWW35D81-02, 35′, Butt Dia. 8″, Wall Thickness .188″
IWW40C71-02, 40′, Butt Dia. 7″, Wall Thickness .156″
IWW40C81-02, 40′, Butt Dia. 8″, Wall Thickness .156″
IWW40D81-02, 40′, Butt Dia. 8″, Wall Thickness .188″
IWW40D12-02, 40′, Butt Dia. 10″, Wall Thickness .188″
IWW45D82-02, 45′, Butt Dia. 8″, Wall Thickness .188″
IWW45D12-02, 45′, Butt Dia. 10″, Wall Thickness .188″
IWW50D13-02, 50′, Butt Dia. 10″, Wall Thickness .188″
IWW50F13-02, 50′, Butt Dia. 10″, Wall Thickness .250″
IWW60D13-02, 60′, Butt Dia. 10″, Wall Thickness .188″
IWW60F13-02, 60′, Butt Dia. 10″, Wall Thickness .250″
IWW60F23-02, 60′, Butt Dia. 12″, Wall Thickness .250″
IWW70G13-02, 70′, Butt Dia. 10″, Wall Thickness .312″
IWW70F23-02, 70′, Butt Dia. 12″, Wall Thickness .250″
IWW80H24-02, 80′, Butt Dia. 12″, Wall Thickness .375″



Written Specs blue-checkIWW Ground Set Specifications

• Gold Anodized Aluminum Ball
• Cast Aluminum Revolving Truck Assembly with Stainless Steel Ball Bearings, Aluminum Spindle and Removable Hood (Flagpole heights 50′ and above contain Heavy-Duty Sealed Stainless Steel Ball Bearings)
• Complete Internal Halyard Assembly
– Stainless Steel Wire Cable Halyard
– Two Heavy-Duty Stainless Steel Swivel Snap Hooks
– Two Neoprene Snap Hook Covers
– Beaded Sling Assembly
– Plastic Coated Counterweight
• Stainless Steel Winch Assembly with Removable Hand Crank
• Flush Mount Access Door with Compression Lock and Key
• Spun Aluminum Flash Collar
• Galvanized 16-Gauge Corrugated Steel Ground Sleeve with Steel Grounding Spike

Internal Halyard Flagpole with Winch

IRW and IWW Standard Features
• Gold Anodized Aluminum Ball
• Cast Aluminum Revolving Truck
Assembly with Stainless Steel Ball
Bearings, Aluminum Spindle and
Removable Hood (Flagpole heights 50′
and above contain Heavy-Duty Sealed
Stainless Steel Ball Bearings)
• Complete Internal Halyard Assembly
– Stainless Steel Wire Cable Halyard
– Two Heavy-Duty Stainless Steel
Swivel Snap Hooks
– Two Neoprene Snap Hook Covers
– Beaded Sling Assembly
– Plastic Coated Counterweight
• Stainless Steel Winch Assembly with
Removable Hand Crank
• Flush Mount Access Door with
Compression Lock and Key
• Spun Aluminum Flash Collar
• Galvanized 16-Gauge Corrugated Steel
Ground Sleeve with
Steel Grounding Spike
Optional Features
• Shoe Base Designs for surface mount
installations are available with all
Titan Series – IRW and IWW Flagpoles

Finish Options

American Flagpole is the industry’s unsurpassed leader in aluminum flagpole finish options. In addition to our Standard Satin Aluminum finish, project owners can choose from an unlimited number of Thermoset Powder Paint colors and six standard Anodized finishes.
